Video profiles
29 · G&D IP-Console Client
6. Click Edit .
7. Change the setting(s) of the video profile (see page 29 f.).
8. Click Save to save your settings or discard your changes by clicking Cancel .
Deleting a video profile
How to delete a video profile:
1. Open the control panel with the key combination Ctrl+Shift (default).
2. Click the Target tab.
3. Right-click a target and click on Properties .
4. Click the Video profile tab.
5. Use the Active Profile or Further Profiles paragraph to select the video profile to be
deleted.
6. Click Delete .
Setting options
The user is enabled to edit the profile’s video settings. The following pages describe
the settings that are provided on the different tabs of the window.
The lower window section is identical on all tabs:
The left corner displays the number of image updates per second in the client win-
dow (image frequency) as well as the data transfer rate (in kilobyte per second)
between KVM matrix system and IP-Console Client software.
The following operating elements can also be found in this section:
NOTE: If the active video profile is deleted, the software automatically creates a
new video profile.
display directly: changes in the settings are immediately applied to the image
screen in the client window
Test: applies changes in the settings for the display screen in the client
window
Refresh: synchronizes the transmitted image of the target
Cancel: cancels changes in the settings and close window
Close: temporarily saves settings until the target is accessed again
