HEIDENHAIN CNC PILOT 4290 V7 Aufgaben und Lösungen 12.46
Lösung: Gehaeuse
N11 G37 Q1 F1.5 P0.812 A30 W30 R1.5
N12 G1 X78 B-2
N13 G1 Z-17
N14 G1 X70 Z-19.3094
N15 G1 Z-25
N16 G1 X60 Z-26.3397
N17 G1 Z-33
N18 G1 X78.4602 Z-44
N19 G1 Z-52.0198 B4
N20 G12 X50 Z-67 I40 B0
N21 G1 Z-72.3
N22 G22 Z-68 I40 KI-4 B-0.3
N23 G1 Z-74 B1
N24 G1 X40
N25 G25 H7 I1.15 K5.2 R0.8 W30
N26 G1 Z-98 B-2
N27 G37 Q1 F4.5 P0.92 H3 A30 W30 R1.5
N28 G1 X0
BEARBEITUNG
zentrisches Vorbohren 2 -
32mm - außen - zentrisch -
Stirnflaeche N29 G0 Y0
N30 G14 Q0
N31 G26 S4000
N32 T11
N33 G97 S2288 G95 F0.5 M4
N34 M108
N35 G0 X0 Z5
N36 G147 K2
N37 G74 Z-28.5757 P80 I8 J32 E0.1 K0
N38 G14 Q0
N39 M109
Schruppen - plan - außen -
Stirnflaeche N40 T2
N41 G96 S230 G95 F0.4 M4
N42 M108
N43 G0 X86 Z5
N44 G47 P3
N45 G820 NS12 NE12 P2.5 I1 K0.3 E0 Z-85 A90
W270 Q2 V3 D4
N46 G0 X80
N47 G0 Z5
N48 M109
