HEIDENHAIN CNC PILOT 4290 V7 Aufgaben und Lösungen 12.86
Lösung: Kontur als Insel fräsen, schlichten und entgraten
N12 G102 XK6.6199 YK28.0012 I0 B0
N13 G103 XK6.1642 YK20.0006 I9.3782 B0
N14 G101 XK30 YK0
N15 G101 YK-8
N16 G101 XK68 B0
N17 G103 XK-68 J0 B0
N18 G101 XK-30
N19 G101 YK0
N20 G309
Stirnflächenkontur – Untere
Tasche STIRN Z0
N21 G308 P-5
N22 G100 XK-30 YK0
N23 G101 XK-6.1642 YK-20.0006 B0
N24 G102 XK-6.6199 YK-28.0012 I-9.3782 B0
N25 G103 XK0 YK-50.01 I0 B0
N26 G103 XK6.6199 YK-28.0012 I0 B0
N27 G102 XK6.1642 YK-20.0006 I9.3782 B0
N28 G101 XK30 YK0
N29 G101 YK8
N30 G101 XK68 B0
N31 G102 XK-68 J0 B0
N32 G101 XK-30
N33 G101 YK0
N34 G309
Stirnflächenkontur – Insel STIRN Z0
N35 G308 P-5
N36 G100 XK-30 YK0
N37 G101 XK-6.1642 YK20.0006 B0
N38 G103 XK-6.6199 YK28.0012 I-9.3782 B0
N39 G102 XK0 YK50.01 I0 B0
N40 G102 XK6.6199 YK28.0012 I0 B0
N41 G103 XK6.1642 YK20.0006 I9.3782 B0
N42 G101 XK30 YK0
N43 G101 XK6.1642 YK-20.0006 B0
N44 G103 XK6.6199 YK-28.0012 I9.3782 B0
N45 G102 XK0 YK-50.01 I0 B0
N46 G102 XK-6.6199 YK-28.0012 I0 B0
N47 G103 XK-6.1642 YK-20.0006 I-9.3782 B0
N48 G101 XK-30 YK0
N49 G309
