HEIDENHAIN CNC PILOT 4290 V7 Aufgaben und Lösungen 12.100
Lösung: Zirkulare Nut
Stirnflächenkontur STIRN Z0
N7 G308 P-4
N8 G100 XK20 YK34.641
N9 G102 XK38.4837 YK10.9091 I0 B0
N10 G103 XK42.332 YK8 J12 B0
N11 G101 XK44.4072 B0
N12 G103 XK48.2687 YK13.0435 I44.4072 B0
N13 G103 XK25 YK43.3013 I0 B0
N14 G103 XK-12.8384 YK48.3237 J0 B0
N15 G103 XK-15.2754 YK42.4578 I-11.8113 B0
N16 G101 XK-14.2378 YK40.6606 B0
N17 G103 XK-9.7943 YK38.7824 J42.6606 B0
N18 G102 XK20 YK34.641 J0 B0
N19 G309
STIRN Z0
N20 G308 P-4
N21 G100 XK20 YK-34.641
N22 G102 XK-9.7943 YK-38.7824 J0 B0
N23 G103 XK-14.2378 YK-40.6606 J-42.6606 B0
N24 G101 XK-15.2754 YK-42.4578 B0
N25 G103 XK-12.8384 YK-48.3237 I-11.8113 B0
N26 G103 XK25 YK-43.3013 J0 B0
N27 G103 XK48.2687 YK-13.0435 I0 B0
N28 G103 XK44.4072 YK-8 I44.4072 B0
N29 G101 XK42.332 B0
N30 G103 XK38.4837 YK-10.9091 J-12 B0
N31 G102 XK20 YK-34.641 I0 B0
N32 G309
STIRN Z0
N33 G308 P-4
N34 G100 XK-40 YK0
N35 G102 XK-28.6894 YK27.8733 I0 B0
N36 G103 XK-28.0942 YK32.6606 I-31.5583 B0
N37 G101 XK-29.1318 YK34.4578 B0
N38 G103 XK-35.4303 YK35.2802 J32.4578 B0
N39 G103 XK-50 YK0 I0 B0
N40 G103 XK-35.4303 YK-35.2802 I0 B0
N41 G103 XK-29.1318 YK-34.4578 J-32.4578 B0
N42 G101 XK-28.0942 YK-32.6606 B0
N43 G103 XK-28.6894 YK-27.8733 I-31.5583 B0
N44 G102 XK-40 YK0 I0 B0
N45 G309
