TEILELISTE
6/13/95
HT4001
Betriebsanleitung
7-25
Fernsteuerung – Spannung/Strom
: Digitales Steuermodul (077012)
Teile-
Position
nummer
Beschreibung
bestimmt für
Menge
077012
Control Module, 750A Digital V/C (DR)
1
1
002107
Cov: DR/PR V/C Top
1
2
002106
Cov: DR/PR V/C Bottom
1
3
002119
Panel, Rear, DR V/C
1
4
004119
Bracket, Mtg, DR/PR V/C
1
5
008069
Fuse, 3/8 Amp 250V 1/4 X 1-1/4 Slow
1
6
008165
Fuseholder, Panel mount 1/4 x 1-1/4
1
7
008164
Knob: .735 Dia. 1/4 Sft Black
2
8
014012
Transf'mer, DR/PR/SR Rmt
1
029899
Filter PNL-PCB SA: 077012 RVC
1
9
009871
Potentiometer, 500 Ohm 10 turn
2
10
008175
Receptacle, Shell Size 13-9
5X1
1
11
008176
Pin, 20-24 AWG Type III+ CRP
6
074016
Term 22-18 .250 FEM QC Insul
2
074038
Term 22-18 FEM QC Insul
5
074041
Term 22-18 #6 Ring Uninsul
2
074067
Term 22-18 .25 MAL QC Insul
2
12
041070
PC BD Assy Opto-Iso
1
008097
Terminal, 1/16 Pnl Swg Mt
4
13
041370
PC BD Assy: 750A DR V/C
1
14
004116
Heatsink, DR/PR SR V/C
1
15
042059
IC: Regulator +5V 1.5A
1
16
009274
Capacitor, 2600 UF 15VDC
1
008097
Terminal, 1/16 Pnl Swg Mt
11
008098
Terminal, 1/16 Pnl Prs Mt
9
17
041076
PC BD Assy Rem Volt Disp
1
18
041077
PC BD Assy Rem Curr Disp
1
