Timer/zähler -30 – Hypertherm HT4001 Benutzerhandbuch
Seite 177
Advertising
![background image](/files/789724/content/doc177.png)
TEILELISTE
6/13/95
7-30
HT4001
Betriebsanleitung
Timer/Zähler (073057)
Teile-
Position
nummer
Beschreibung
bestimmt für
Menge
073057
HT4X00 Cntr-Tmr
1
001068
Encl:DCC/PCC/RCC RVR
1
2
001391
Pnl:Cntr-Tmr Rear
1
3
001392
Pnl:Cntr-Tmr Front
1
4
005161
PB Sw:Blk SPST NO Sub-Mini
2
5
008176
Pin:24-20 AWG Type III + CRP
4
6
008193
RCPT Shell:CPC 17-16 Std Sex
11X1
1
7
027274
Counter, Self Powered LCD
2
8
027275
Meter, Self Powered ET
1
–
003140
Relay:120VAC DP AU Cont
2
G
Abbildung 7-14
Timer/Zähler
1
7
6
5
8
7
2
4
3
4
