STANDARD-KOMPONENTEN
22
HySpeed HT2000 Betriebsanleitung 9-15
HT2000-Stromquelle
ቢ
: Innenseite der Rückwand
Teile-
Position nummer Beschreibung bestimmt für Menge
1 009684 Res: 4 Ohm 420W w/bracket R6A,R6B 2
2 003021 Relay, 120VAC NO SPST CR1 1
3 009015 Res: 10K Ohm, 10W R5 1
4 009506 Cap: 250µF, 350VDC C1 1
5 009438 Res: 5 Ohm, 50W R4 1
6 008610 Strain Relief, 1-1/2 NPT, 1.5 ID 2 Screw 1
7 001378 Panel, HT2000 Rear 1
8 008500 Strain Relief, 1/2 X .125-.375 1
9 041274 PC BD Assy, ISO PCB11 1
10 028666 Timer/Counter 1
004545 Bracket 1
027274 Counter, Self Powered 2
027275 Meter, Elapsed Time 1
003140 Relay; 120VAC 2
009204 Capacitor 3
029645 Harness SA HT2000
11 008079 Terminal Strip (8) TB4 1
12 008073 Terminal Strip (16) TB3 1
13 008447 Receptacle, 23-37, Std Sex 1X6, 1X5 2
14 008208 Receptacle, 23-37, Rev Sex 1X1,1X2, 1X3 5
1X7, 1X4
15 008201 Receptacle, 17-14, Rev Sex 1X9 1
16 008210 Receptacle, 11-4, Rev Sex 1X10 1
