STANDARD-KOMPONENTEN
24
HySpeed HT2000 Betriebsanleitung 9-55
Empfohlene Ersatzteile
Stromquelle
Seiten-
Teilenummer Beschreibung bestimmt für Menge bezug
005121 Pushbutton: 2 NO Green Illumin PB1 1 9-6
005122 Pushbutton: 2 NC Red Extended PB2 1 9-6
005149 Bulb: 120VAC LT2 2 9-6
027080 Fan: 225CFM 120VAC 50/60 Hz M2,M3 1 9-5
027079 Fan: 450-550 CFM 120VAC 50/60 Hz M4 1 9-5
041762 PCB Assy: HT2000 Control II PCB2 1 9-5
081039 Firmware: HT2000 2 9-5
041246 PCB Assy: Relay, HD1070/HT2000 PCB4 1 9-5
041294 PCB Assy: HT2000 THC Mother PCB9 1 9-5
041186 PCB Assy: HT2000 THC PCB10 1 9-5
005102 Thermostat: 160°C, 6 Amp TS1 1 9-7
003138 Circuit Breaker, 2 Pole, 600V 100A CB1 1 9-9
003139 Contactor: 90A 3 Pole, 120VAC CON1 2 9-9
041534 PCB Assy: Power Distribution PCB1 1 9-9
008317 Fuse: Semiconductor 125A, 250V F1,F2 5 9-11
129118 CH130 Chopper SA CH1,CH2 1 9-13
009684 Res: 4 Ohm 420W w/bracket R6A,R6B 2 9-15
003021 Relay, 120VAC NO SPST CR1 1 9-15
009794 Coil: Air Core Transformer, 8AWG T1 1 9-17
029202 Current Sensor SA CS1 1 9-17
129618 Switch, Level SA, 1/2 NPT LS1 1 9-19
029323 Switch, Temp SA, 162 Deg. F TS2 1 9-19
029361 Flowswitch SA, Reservoir FS1 1 9-19
006046 Valve, Sol 240V 3/8 NPT NC V1 1 9-19
128384 Kit: Pump, 70 GPH Positive Displace 1 9-19
Hochfrequenz-Konsole
Seiten-
Teilenummer Beschreibung bestimmt für Menge bezug
009224 Cap: Poly .22µF 10% 1000 C1,C2 2 9-21
009280 Cap: .022µF 15kV C3,C4 2 9-23
004061 Electrode:Sprk Gap 1/8 x 1.6 3 9-23
129150 HV Transformer SA, 5000V, 20 ma T1 1 9-21
005227 Switch, Pressure 12 psi PS3 1 9-21
006032 Solenoid Valve:150# 1/4 FPT 120V NC SV6 1 9-21
006106 Solenoid Valve: 120VAC 1/8FPT SV7 1 9-21
