Guntermann & Drunck GmbH Operating Instructions LwLVision
Page 36
Confirm you entry with
Enter . Then the following window will open.
D D C I N F O L W L M
M o n i t o r L o c a l A n a l o g
Horiz. frequ. min.:
30 kHz
Horiz. frequ. max.: 130 kHz
Vert. frequ. min.: 50 Hz
Vert. frequ. max.: 200 Hz
Pixel frequ. max. 2550Hz
Separate sync support Yes
Composite sync support Yes
Sync on green support Yes
Standby support Yes
Suspend support Yes
Powersave support Yes
GTF support No
Vendor ID IVM
Type HM903D/DT
Esc:
quit this menu
Blank: select Monitor
F4: go to Rem Screen Config
With
Esc you stop the entry and go back to the menu SELECT MONITOR.
In order to switch between the different monitor information, press space bar
(blank).
With
F4 you go back to the menu REM SCREEN CONFIG.
In this menu you get information about the maximum performance of your
monitor. With this information you know which values are to be selected in
REM SCREEN CONFIG.
If you set the values for the resolution in REM SCREEN CONFIG to the
maximum you will see no picture on your screen.
The monitor can also use only such refresh rates who are possible on the basis
of its specifications and independent from the input signal at the LwLVision-
PC (e.g. the graphics card of the PC connected to LwLVision-PC transmits 85
Hz but the monitor at the LwLVision-Rem can only work with 75 Hz, so the
result is 75 Hz).
