Guntermann & Drunck GmbH Operating Instructions LwLVision
1 Description
The LwLVision system consists of a transmitter and a receiver and makes it
possible to control a computer from a distance of up to 550 m (10 000 m). A
local console can also be connected to the transmitter. Operation can be done
either local or remote.
The transmission of the signals monitor, keyboard and mouse is done via 2-
fibre optical fibre cable which either is
 a single mode fibre cable (10 000 m) or
 a multi mode fibre cable (550 m).
For every fibre exists a determined LwLVision system.
In addition to the monitor, keyboard and mouse information serial signals are
transmitted via RS232 interface.
Also audio signals in CD quality can be transmitted via optical fibre cable.
ision -PC
L L Active
Local Power CPU
Status
Red.
Main
Front panel LwLVision-PC
ision -Rem
L L Active
Local Power
Status
Red.
Main
Front panel LwLVision-Rem
Page 7
