Guntermann & Drunck GmbH Operating Instructions LwLVision
Page 64
Power Supply
Main Power Supply Redundant Power Supply
LwLVision-PC 100 – 240 VAC primary
50 – 60 Hz, 0,3A 12 VCD, 1,2 A
LwLVision-Rem 100 – 240 VAC primary
50 – 60 Hz, 0,5A 12 VCD, 2,2 A
LwLVision/MC2-PC 100 – 240 VAC primary
50 – 60 Hz,0,4A 12 VCD, 1,9 A
LwLVision/MC2-Rem 100 – 240 VAC primary
50 – 60 Hz, 0,6A
12 VCD, 3,0 A
Optical Specifications:
Property LwLVision (M) LwLVision (S)
Launched Power (P
OUT
) -9.5 dBm (min.)
(1)
-4 dBm (max.)
(1)
-9.5 dBm (min.)
(2)
-3 dBm (max.)
(2)
T
rans- mitter Center Wavelength 850 nm
(830 nm - 860 nm) 1310 nm
(1270 nm - 1355 nm)
Optical Input Power-
maximum (P
IN
)
0 dBm (min) -3 dBm (min)
Sensitivity (P
IN
) -18 dBm (max)
(1)
-20 dBm (max)
(2)
Receiv
er
Stressed sensitivity -13.5 dBm (max)
(1)
-14.4 dBm (max)
(2)
(1) With 50 µm single mode faser.
(2)
With 9 µm single mode faser.
