Guntermann & Drunck GmbH Operating Instructions LwLVision
Page 53
Confirm with Enter . Then the following window will open:
D D C I N F O L W L M
M o n i t o r L o c a l A n a l o g
Horiz. frequ. min.:
30 kHz
Horiz. frequ. max.: 130 kHz
Vert. frequ. min.: 50 Hz
Vert. frequ. max.: 200 Hz
Pixel frequ. max. 2550Hz
Separate sync support Yes
Composite sync support Yes
Sync on green support Yes
Standby support Yes
Suspend support Yes
Powersave support Yes
GTF support No
Vendor ID IVM
Type HM903D/DT
Esc:
quit this menu
Blank: select Monitor
With
Esc you stop the entry and go back to the menu SELECT MONITOR.
In order to switch between the different monitor information, press
Space
(Blank).
In this menu you will get information about the maximum performance of your
monitor. With this information you know which values are meaningful for REM
SCREEN CONFIG (
see chapter 7.2.3.2 ).
If you set the value (e.g. in REM SCREEN CONFIG) to the maximum possible
resolution of the monitor you will have no picture on your screen.
The monitor can only work with such refresh rates that are possible on the
basis of its specifications, independent from the input signal at the LwLVision-
PC (e.g. the graphics card transmits 85 Hz to the computer connected to the
LwLVision-PC but the monitor at the LwLVision-Rem can only work with 75
Hz, so the result is only 75 Hz).
