Guntermann & Drunck GmbH Operating Instructions LwLVision
7.2.3.3.9 Activation of the Protected Mode
With this setting you define whether the Protected Mode (see
chapter 8.4
) is
to be activated.
Move the cursor to the entry Protected Mode.
By pressing
SPACE
you can chose between Yes or NO.
In order to save the settings and close the menu, press
F1
.
After having activated the Protected Mode the following message appears on
the display:
LWLM
PROTECTED MODE ENABLED
7.2.3.3.10 Keyb. LED flash
With this setting you define whether the keyboard LEDs should flash after
having activated the hold function (see
chapter 8.3
) or not.
Move the cursor to the entry Keyb. LED flash.
By pressing
SPACE
you can chose between Yes or NO.
In order to save the setting and close this menu, press
F1
.
7.2.3.3.11 Definition of the local Scan Code
The scan code is the “language” for the communication between keyboard and
computer. LwLVision works with scan code 2.
Change this setting only in accordance with our service department.
Move the cursor to the corresponding entry.
By pressing
SPACE
you can chose between 3 or 2.
In order to save the setting and close the menu, press
F1
.
7.2.3.3.12 Definition of the remote Scan Code
Function correspondent to
chapter 7.2.3.3.11
but related to the remote
keyboard.
Page 41
