Guntermann & Drunck GmbH Operating Instructions LwLVision
7.2 Configuration at the LwLVision-Rem via OSD
(AdonIS)
The LwLVision system at the remote console (LwLVision-Rem) is equipped
with an OSD. Via OSD (
AdonIS ) you can adjust the whole system to your
needs.
With CTRL + NUM you open AdonIS :
F u n c t i o n L W L M
F2: Image Config
F3: Console Setup
F6: Config
F8: Logout
Mouse
Utility
System Info
Video Info
Monitor Info
Esc Enter
Page 24
In the Function Menu the following configuration options are available:
 F2 : Image Config (see chapter 6.3.1 )
 F3 : Settings at the console (see chapter 7.2.2 )
 F6 : Main configuration menu; here you can also call up Image
Config, adjust the remote monitor, compile User Accounts,
make system settings (see
chapter 7.2.3 )
 F8 : manual logout
 Mouse Utility: Reinitialization of the connected mouse if initialization
is lost (see
chapter 7.3 )
The Function Menu also delivers the following information:
 System Info: Information about the used LwLVision system
(e.g. Revision status, keyboard/Mouse protocol, actual
user...) (see
chapter 7.4 )
 Video Info: Information about the display parameters at the signal
input of the LwLVision-PC (see
chapter 7.5 ).
 Monitor Info: Information about the signals used from the monitor
(only for DDC monitors) (see chapter 7.6 )
