Guntermann & Drunck GmbH Operating Instructions LwLVision
Page 18
6 Video
6.1 Supported Resolutions
The LwLVision system supports the following resolutions:
Input resolution
Local out Remote out
(1)
640 × 350 @ 60-120 Hz as input 640 × 350 @ 70/85 Hz
640 × 400 @ 50-120 Hz as input 640 × 400 @ 85 Hz
640 × 480 @ 50-120 Hz as input 640 × 480 @ 60/72/75/85 Hz
720 × 400 @ 50-120 Hz as input 720 × 400 @ 70/85 Hz
800 × 600 @ 50-120 Hz as input 800 × 600 @ 60/72/75/85 Hz
1024 × 768 @ 50-120 Hz as input 1024 × 768 @ 60/70/75/85 Hz
1152 × 864 @ 50-85 Hz as input 1152 × 864 @ 75 Hz
1152 × 900 @ 50-76 Hz as input 1152 × 900 @ 66 Hz
1280 × 720 @ 50-85 Hz as input 1280 × 720 @ 60 Hz
1280 × 768 @ 50-100 Hz as input 1280 × 768 @ 60 Hz
1280 × 960 @ 50-75 Hz as input 1280 × 960 @ 60/85 Hz
1280 × 1024 @ 50-75 Hz as input 1280 × 1024 @ 60/75/85 Hz
1360 × 768 @ 50-85 Hz as input 1360 × 768 @ 60 Hz
1400 × 1050 @ 50-75 Hz as input 1400 × 1050 @ 60 Hz
1440 × 900 @ 50-85 Hz as input 1440 × 900 @ 60 Hz
1600 × 1050 @ 60 Hz as input 1600 × 1050 @ 60 Hz
1680 × 1200 @ 60 Hz as input 1680 × 1050 @ 60 Hz
1920 × 1080 @ 60 Hz as input 1920 × 1080 @ 60 Hz
1920 × 1200 @ 60 Hz as input 1920 × 1200 @ 60 Hz
(1) According to your settings in the menu Remote Screen Config video refresh rate and resolution
can be different.
Input signal Local
digital out Local
analog
out Remote
digital out Remote
analog
out
Analogue Input (VGA)
n.a.
(2)
Ok Ok Ok
Digital Input (DVI)
Ok n.a. (3)
Ok Ok
Analogue and digital Input
(DVI+VGA)
(4)
Ok Ok Ok Ok
(2) At the local output there is only one digital signal available if also a digital signal is fed (from the
computer) or both: analogue and digital.
(3) At the local output there is only one analogue signal available if also an analogue signal is fed
(from the computer) or both: analogue and digital.
(4) If a digital and analogue input signal is available, the digital signal will be used for the
transmission.
