Seite 228
212
9440375990 Rev H
PGN
Name
Einheit
SPN
Übertragungs-
rate
Generator mittlere AC Frequenz
Hertz
2436
Generator mittlerer AC RMS Strom
Ampere
2448
0xFE04
Generator Gesamtblindleistung
VAr
2456
100 ms
Generator Gesamt PF
entfällt
2464
Generator Gesamt PF Nacheilung
entfällt
2518
0xFE05
Generator Gesamtwirkleistung
Watt
2452
100 ms
Generator Gesamtscheinleistung
VA
2460
0xFF00
Kontakt E/A Status
Start Eingang - Byte 0, Bits 0,1
Stopp Eingang - Byte 0, Bits 2,3
Eingang 1 - Byte 0, Bits 4,5
Eingang 2 - Byte 0, Bits 6,7
Eingang 3 - Byte 1, Bits 0,1
Eingang 4 - Byte 1, Bits 2,3
Eingang 5 - Byte 1, Bits 4,5
Eingang 6 - Byte 1, Bits 6,7
Eingang 7 - Byte 2, Bits 0,1
Eingang 8 - Byte 2, Bits 2,3
Eingang 9 - Byte 2, Bits 4,5
Eingang 10 - Byte 2, Bits 6,7
Eingang 11 - Byte 3, Bits 0,1
Eingang 12 - Byte 3, Bits 2,3
Eingang 13 - Byte 3, Bits 4,5
Eingang 14 - Byte 3, Bits 6,7
Wächter Ausgang - Byte 4, Bits 0,1
Ausgang 1 - Byte 4, Bits 2,3
Ausgang 2 - Byte 4, Bits 4,5
Ausgang 3 - Byte 4, Bits 6,7
Ausgang 4 - Byte 5, Bits 0,1
Ausgang 5 - Byte 5, Bits 2,3
Ausgang 6 - Byte 5, Bits 4,5
Ausgang 7 - Byte 5, Bits 6,7
Ausgang 8 - Byte 6, Bits 0,1
Ausgang 9 - Byte 6, Bits 2,3
Ausgang 10 - Byte 6, Bits 4,5
Ausgang 11 - Byte 6, Bits 6,7
Hinweise
0 = Offen
1 = Geschlossen
2 = Reserviert
3 = Reserviert
entfällt
entfällt
100 ms
0xF015
Angeforderte Generator Gesamt- AC Blindleistung (VAr Sollwert)
VAr
3383
entfällt
Angeforderter Generator Gesamt PF (PF Sollwert)
entfällt
3384
entfällt
Angeforderte Generator Gesamt PF Nacheilung (PF Sollwert)
entfällt
3385
entfällt
0xF01C
Angeforderte Generator mittlere L-L AC RMS Spannung
(AVR Sollwert)
Volt
3386
entfällt
CAN Kommunikation
DECS-250
