Messung, Modbus™ kommunikation decs-250, Tabelle 25. parameter der messungsgruppe – Basler Electric DECS-250 Benutzerhandbuch
Seite 252
236
9440375990 Rev H
Gruppe
Name
Register
Typ
Bytes
R/W
Bereich
Netzwerklastverteilung
Empfangende ID 1
40926 bit 14
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 2
40926 bit 15
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 3
40927 bit 0
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 4
40927 bit 1
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 5
40927 bit 2
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 6
40927 bit 3
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 7
40927 bit 4
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 8
40927 bit 5
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 9
40927 bit 6
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 10
40927 bit 7
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 11
40927 bit 8
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 12
40927 bit 9
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 13
40927 bit 10
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 14
40927 bit 11
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 15
40927 bit 12
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
Empfangende ID 16
40927 bit 13
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS-Konfiguration-
Nichtübereinstimmung
40927 bit 14
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS Fehlende ID
40927 bit 15
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 1 Aktiviert
40928 bit 0
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 2 Aktiviert
40928 bit 1
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 3 Aktiviert
40928 bit 2
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 4 Aktiviert
40928 bit 3
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 5 Aktiviert
40928 bit 4
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 6 Aktiviert
40928 bit 5
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 7 Aktiviert
40928 bit 6
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 8 Aktiviert
40928 bit 7
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 9 Aktiviert
40928 bit 8
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 10 Aktiviert
40928 bit 9
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 11 Aktiviert
40928 bit 10
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 12 Aktiviert
40928 bit 11
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 13 Aktiviert
40928 bit 12
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 14 Aktiviert
40928 bit 13
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 15 Aktiviert
40928 bit 14
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
ID 16 Aktiviert
40928 bit 15
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS Status 1
40929 bit 0
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS Status 2
40929 bit 1
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS Status 3
40929 bit 2
Uint16
2
R
True=1 False=0
Netzwerklastverteilung
NLS Status 4
40929 bit 3
Uint16
2
R
True=1 False=0
Messung
Tabelle 25. Parameter der Messungsgruppe
Gruppe
Name
Register
Typ
Byte
R/W
Einheit
Bereich
Feld-Voltmesser
V
X
41000
Gleitkomma
4
R
Volt
-1000 - 1000
Feld-Stromesser
I
X
41002
Gleitkomma
4
R
Ampere
0 -
2000000000
DECS-PSS-MESSER
Klemmenfrequenz
Abweichung
41004
Gleitkomma
4
R
Keine
Einheit
n.z.
DECS-PSS-MESSER
Kompensierte
Frequenz
Abweichung
41006
Gleitkomma
4
R
Keine
Einheit
n.z.
Modbus™ Kommunikation
DECS-250
