II Technical Information
II - 1 Installation, and Electr
ical Connection
II - 1 Installation, and Electrical
Connection
Items Supplied
 ND 780 Display Unit
 Power connector
 User's Manual
Accessories
 Tilting base
 Tilting Bracket Assembly
 Universal Mounting Arm
 KT 130 Edge Finder
 Handle
 Mounting Frame
ND 780 Display Unit
Mounting Location
Locate the unit in a well ventilated area such that it may be easily
accessed during normal operation.
Installation
M4 screws are used to secure ND 780 from below. For the hole
locations: See "Dimensions" on page 115.
Electrical connection
There are no serviceable items within this unit. Therefore,
the ND 780 must never be opened.
The length of the power cord is not to exceed 3 meters.
Connect a protective ground to the protective conductor
terminal on the rear of the unit. This connection must never
be interrupted.
Do not engage, or disengage any connections while the
unit is under power. Damage to internal components may
result.
Use only, original replacement fuses.
