ND 780
111
II - 6 Specifications f
o
r Milling
ND 780 Data
Error compensation
Linear, and non-linear, up to 200 measuring points
Backlash compensation Rotary encoder applications with ballscrews
Data interface  Serial:
RS-232-C/V.24
300 to 115 200 baud
For output of measured values, and parameters;
For input of parameters, remote keys, and commands
Accessories  Tilting Base
 Universal Mounting Arm
 KT 130 Edge Finder
 Tilting Bracket Assembly
 Handle
 Mounting Frame
Main power input AC 100 V ... 240 V (±10 %); 50 Hz ... 60 Hz (±3 Hz);
power consumption max. 135 W
Operating temperature 0°C to 45°C (32 °F to 113 °F)
Storage temperature -20°C to 70°C (-4°F to 158°F)
Degree of protection (EN 60529) IP 40 (IP 54 front panel)
Weight
2.6 kg
