ND 780
107
II - 5 Measur
ed V
a
lue Output
Data output using Edge Finder
In the next three examples, measured value output is started with a
switching signal from the edge finder.
Printing capability can be
turned on, or off in the Job Setup parameter Measured Value Output.
Information from here is transmitted from the selected axis.
Example 4: Probing function Edge Y = –3674.4498 mm
1
Coordinate axis
2
2 blank spaces
3
Colon
4
+/– sign, or blank space
5
2 to 7 places before the decimal point
6
Decimal point
7
1 to 6 places after the decimal point
8
Unit: blank space for mm, “ for inches
9
R for radius display, D for diameter display
10
Carriage return
11
Blank line (Line Feed)
Y
:
-
3 6 7 4
.
4 4 9 8
R <CR>
<LF>
1
2
3
4
5
6
7
8
9
10
11
