rs II - 3 Encoder Parameters
The following tables represent a partial list of encoders. These tables
describe all operating parameters which must be set for the encoders.
Most entries can be found in the operating instructions for the
encoder.
Example settings for HEIDENHAIN linear encoders with 11-µA
PP
signals
Example settings for HEIDENHAIN linear encoders with 1-V
PP
signals
Encoder Signal period Reference marks
CT
MT xx01
2 Single
LS 303/303C
LS 603/603C
20 Single/
1000
LS 106/106C
LS406/406C
20 Single/
1000
LB 302/302C 40 Single/2000
LM 501 10 240 Single
Encoder Signal period Reference marks
LIP 382 0.128 –
MT xx81
LIP 481A/481R
2 Single
LIP 481X 2 Single
LF 183/183C
LF 481/481C
LIF 181/181C
LIP 581/581C
4 Single/5000
LS 186/186C 20 Single/1000
LB 382/382C
LIDA 18x/18xC
40 Single/
2000
VM 182 4 –
LIDA 10x/10xC 100 Single/1000
LIM 581 10 240 Single
