98
II Technical Information
II - 3 Encoder P
ar
amet
ers
Example settings for HEIDENHAIN rotary encoders
Encoder Line count Reference marks
ROD 250, RON 255 9 000/18 000 1
ROD 250C, RON 255C 9 000 500
ROD 250C, ROD 255C
ROD 700C, RON 705C
RON 706C
18 000 1 000
ROD 700C, ROD 800C 36 000 1 000
