3-80
TNC 407/TNC 415/TNC 425 16 Anschlußmaße 11.97
PA 110
X2 X3 X6
24V
X4 X5
X7 X8 X9 X10
92+1
3.62+.04"
16.5 .65"
205+1
8.07+.04"
Masseanschluß M5
GROUND CONNECTION
30
1.18"
42+1
1.65+.04"
1.5+0.5
.06+.02"
Montageschiene nach DIN 50022
MOUNTING SPAR AS PER DIN 50022
60
±
0.2
2.362
±
.008"
5.5
.217"
32.5
1.28"
140
±
0.2
5.512
±
.008"
3
.12"
X1
