676 Configuration
Stop determination
The running determination will be automatically terminated. The following
message must be confirmed with [OK] .
855 Robotic Titrosampler
The parameters for the 855 Robotic Titrosampler are set on the following tabs:
• General
General device information such as device name, device type, serial num-
ber, etc.
• Measuring inputs
Properties of the measuring inputs.
• MSB #
Properties of the MSB connections 1...3 and the peripheral devices con-
nected to them.
• Tower 1
Properties of Tower 1.
• Rack
Information about the attached rack.
• GLP
Information about GLP test and GLP monitoring.
General
Device name
50 characters, [ device type number_# ]
Name of device (can be freely defined by user).
Device type
Shows the type of device.
Program version
Shows the program version of the device.
Opens the dialog window Load new program version . This button is only ac-
tive when the device has an old program version that is not supported by
tiamo which can be updated by tiamo itself.
Device serial number
Shows the serial number of the device.
