346
6 DIN-Programmierung
6.16 F
reistic
hzyklen
Freistichwinkel (bei DIN 509 E und F): 15°
Planwinkel (bei DIN 509 F): 8°
Freistichparameter DIN 509 E (Maße in mm)
Durchmesser
Freistich-
tiefe I
Freistich-
länge K
Freistich-
radius R
< 18
0,25
2
0,6
> 18 - 80
0,35
2,5
0,6
> 80
0,45
4
1
Freistichparameter DIN 509 F (Maße in mm)
Durchmesser
Freistich-
tiefe I
Freistich-
länge K
Freistich-
radius R
Plantiefe P
< 18
0,25
2
0,6
0,1
> 18 - 80
0,35
2,5
0,6
0,2
> 80
0,45
4
1
0,3
